Crawler Mining Core Drilling Rig

Crawler Mining Core Drilling Machine Rig

YDX-Series mining core drilling machine is one kind of hydraulic top drive rotary head type diling rig which is mainly used in diameter diamond diling of metal and nonmetal solid deposit exploration. It can also be used in carbide bit core drilling. It is used to bore verical holes as well as inclined holes, which is also applied in engineering boreholes of hydrology water wells, petroleum or gas field exploration, dike & dam cement grouting, tunnel ventilation and water draining, etc.

Model		YDX-1200L	YDX-120OT
Borehole Diameter/ Depth		BQ/1400m; NQ/1200m; HQ/850m; PQ/600m
Drill Angle		-90~0°
Drill Head Rotary Speed(FR/RE)		113-165rpm; 237-345rpm; 437-636rpm; 750-1100rpm
Max Output Torque of Drive Power Head		5270Nm
Drill Head Feeding Stroke		3500mm
Drill Head Max. Lifting Force		108KN
Drill Head Max. Thrust Force		55KN
Main Winch (Lifting Drill Rod)	Max Lifting Ability	75KN
	Hoisting Speed	0.62m/s
Assistant Winch (Wire-line Coring)	Max Lifting Ability	1200KN
	Hoisting Speed	2.01m/s
Mast Sliding Distance		800mm
Engine Model		6BTA5.9-C125
Engine Power		125KW/2000rpm
Chassis Model		Crawler type (YDX-1200)L	Trailer-mounted (YDX-1200)T
Overall Dimension(Drill Reduce Type)		5300×2200×2820mm	5300×1950×2200mm
Drilling Rig Weight,appx.		7800kg	6500kg
